Celestron CGX Equatorial Mount

RM 11,000.00


Celestron CGX Equatorial Mount

For eight years, Celestron’s workhorse CGEM mount lineup has been the German Equatorial backbone for telescopes ranging from 6 to 11 inches of aperture. Since that time, many more astro-imagers and planetarium controlled setups have emerged as backyard telescope technology has evolved. Celestron’s engineering team applied their years of experience designing German Equatorial mounts to the all-new CGX EQ, a culmination of all the advancements made to our technologies, value, and ease-of-use.

The  CGX was designed to better support your telescope for both visual and astro-imaging pursuits. Key design goals included a lower profile EQ head, which provides a more compact and therefore more stable setup; a better drive system; remote operation-friendly with home and limit optical sensors; easier polar alignment adjustments; and better cable management. In addition to that, we’ve made mechanical and ergonomic improvements throughout to make the mount sturdier, easier to use, and transport. The CGX is our Equatorial backbone to support a wide range of telescopes.




Specifications

  • Computerized Equatorial Mount
  • 25Kg Payload Capacity
  • 3-65 Degree Operation Latitude
  • Belt Driven Worm Gear With Spring Loaded System
  • Support Both Vixen And Losmandy Dovetail Bar
  • Mount Head Weight : 20Kg
  • Tripod Weight : 8.7Kg
  • Total Weight Exclude Counterweight : 28.7Kg
  • Tracking Mode : Sidereal, Lunar, Solar
  • GoTo System : Celestron Nexstar System With 40,000+ Object Database
  • Alignment : 2-Star Align, 1-Star Align, Solar System Align, Last Alignment, Quick Align
  • Tripod : 2'' Stainless Steel Tripod
  • Motor Type : DC Servo Motor
  • Power Requirement : 12V 3A



Included Items

  • Celestron CGX Mount
  • 2x 5Kg Counterweight
  • Celestron Nexstar Hand Controller
  • Hand Controller Holder
  • 12V Power Cable (Cigar Port)
  • Accessories Tray
  • 2 Years Warranty


Delivery leadtime Estimated 4 Months
